OPERATING INSTRUCTIONS STEP 2
STEP 3
NOTE: The quick coupler can work efficiently with hydraulic hammers, but too long periods of such work should be avoided. When you use a hydraulic hammer, you must always orientate the hammer towards the machine and never use it as a lever, since all stresses would be imposed on the quick coupler hydraulic cylinder. The quick coupler is not designed to be subjected to prolonged excessive vibration. We therefore recommend you to remove the quick coupler to reduce the risk of needless premature wear, failures or breakage.
CD00A010
Take the bucket or clamshell selector valve levers out of the tool box and install them on the selector valve.
149
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
CD00A011
Turn the levers to the left, in closed position, then remove the levers and put them back in the tool box.
TRIM THIS EDGE
CD00D002
Retract the bucket cylinder rod as far as possible. Stop the engine and remove the starter switch key.
Alt= to hide template information Alt+ to display template information
STEP 4
