OPERATING INSTRUCTIONS
CAB REMOVAL AND INSTALLATION Removal
STEP 3
Template Name: OM_1_col Template Date: 1994_04_29
Tools required - One 10 mm wrench for hexagonal head screws - One 22 mm wrench for hexagonal head screws - Suitable lifting equipment NOTE: The weight of the cab is 295 kg. STEP 1 Park the machine on flat, level ground.
PH07911
Disconnect the electrical power point from its base. Install the protective cap on the base. Disconnect the windshield washer hose. Disconnect the cab radio aerial (if equipped).
STEP 2
TRIM THIS EDGE
STEP 4
Alt= to hide template information Alt+ to display template information
PH07909
Remove the trim located behind the seat.
PH07824
Remove the two plastic plugs from the cab roof and install suitable lifting equipment.
136
