OPERATING INSTRUCTIONS
- Use slings, belts, fittings and chains which are in perfect condition and which are equipped with safety type hooks that will not accidentally open. - Use a means of guidance while handling and use handling equipment which is conformance with regulations. - Do not allow anyone to remain within the working range of the hydraulic breaker while it is being handled. - Attach the slings and chains as shown below.
1
CS99C627
BREAKING TECHNIQUES WITH THE HYDRAULIC BREAKER (optional) To increase the hydraulic breaker’s working life, pay particular attention to correct working methods and to the correct choice of tool for the job. There are essentially two ways of breaking with a hydraulic breaker.
Breaking by penetration (or cutting) In this form of breaking a moil point or chisel tool is forced inside the material. This method is most effective in soft, layered or plastic, low abrasive material. The high impact rate of the small breakers makes them ideal for penetrative breaking.
125
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
NOTE: It is mandatory for the lifting ring (1) to be removed and the ring hole plugged before using the hydraulic breaker.
Template Name: OM_1_col Template Date: 1994_04_29
The lifting equipment must be strong enough to take the weight of the hydraulic breaker. See “Hydraulic breaker” in the “Specifications” Section.
Alt= to hide template information Alt+ to display template information
HANDLING THE HYDRAULIC BREAKER (optional)
