CONTROLS/INSTRUMENTS/ACCESSORIES
ROTARY BEACON (specific to certain countries)
STEP 1
PG02702
Tighten the wing nut. PG02700
Remove the protective cap from the end of the tube located at the top of the cab. STEP 2
IMPORTANT: The rotary beacon must be on when travelling. IMPORTANT: When removing the rotary beacon, make sure to put the cap back on the end of the tube. NOTE: To replace the bulb see “Replacing a bulb” in the “Electrical System” Section.
PG02702
Place the rotary beacon on the end of the tube.
109
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
The rotary beacon is turned on and off by the switch on the instrument panel.
Alt= to hide template information Alt+ to display template information
STEP 3
Template Name: OM_1_col Template Date: 1994_04_29
The rotary beacon must be installed for road travel. See “Road travel” in the “Job Site and Road Operation” Section.
