Section 3. Systems Overview
Model 9600/9700 Swing-Reach ® Lift Truck
Modes of Operation •
Use the up/down buttons to switch between pages 1 and 2 of the log.
•
Use the left/right buttons to exit the log back to the Maintenance Mode menu.
•
If the log displays the message Error Log is empty, no error codes were recorded since the log was last cleared.
•
To clear and reset the Event Log, select Clear and press Enter. On the Clear menu, select Yes with the down button, then press the Enter button. The log is cleared and the display returns to the Maintenance Mode menu.
6. The Operator Display then shows in large letters: Configuration Download in Progress 7. Wait for the download to complete (approx. 45 seconds to 1 minute). When the download has completed, the Operator Display shows: Configuration Download Complete 8. Step off both deadman pedals. Turn the key switch OFF. 9. Turn the key switch ON. The lift truck should go through normal SelfTest.
Using Active Maintenance Mode (ActMaint) Active Maintenance Mode allows inputs to be displayed while the truck is in Run mode. ActMaint is enabled in Configure Mode. Refer to “Using Configure Mode” on page 3-13. 1. While in Run Mode (while time and date are displayed), use the up/down buttons to scroll to either Analog or Input and press Enter. 2. Use the up/down buttons to scroll to the desired item. Refer to “Analog Tests” on page 6-39 and “Input Tests” on page 6-77.
Graphics Database Download Perform a graphics database download: •
if the Operator Display shows Code 57 and the truck is operational
•
the Display Interface Card is replaced
•
anytime the truck software is updated
To do this: 1. Turn the key switch OFF. 2. Press and hold the lift select button. 3. Step on and hold both deadman pedals. 4. Turn the key switch ON. 5. Press and release the lift select button three times.
3-28
Publication: 1089040, Issued: 08 Apr 2016
