Section 3. Systems Overview
Model 9600/9700 Swing-Reach ® Lift Truck
Modes of Operation 11. To save the value, press the Enter button. Select Save? Y and press Enter. 12. Learn Rail Guidance is complete.
Using Maintenance Mode To place the lift truck in Maintenance Mode: 1. Enter Superword. 2. From the Program Mode Superword Level menu, use the up/down buttons to select Maint, then press the Enter button. The selected menu item is indicated by an arrow to the left of the selection. 3. The Maintenance Mode menu is displayed: • Analog • Input • Output • Wire Guidance • EvtLog • Quit Mnt Use the up/down buttons to select the category desired, then press the Enter button.
Analog Tests When Analog is selected, Analog Tests are displayed in numerical sequence. Use the up/down and left/right buttons to scroll to the desired test. To display the selected test, press the Enter button. The Operator Display shows the test number and its status. To return to the Analog Test menu, press the left or right button. Refer to “Analog Tests” on page 6-39.
Input Tests When Input is selected, Input Tests are displayed in numerical sequence. Use the up/down buttons to scroll to the desired test. To display the selected test, press the Enter button. The Operator Display shows the test
3-26
number and its status. To return to the Input Test menu, press the left or right button. Refer to “Input Tests” on page 6-77.
Output Tests When Output is selected, Output Tests are displayed in numerical sequence. Use the up/down and left/right buttons to scroll to the desired test.
When performing an output test, elevate the drive tire off the floor. See “Main Manifold” on page 7-70. Open the Emergency Lowering Valve. See “Main Manifold” on page 7-70. To “run” a selected test, press the Enter button. The Operator Display prompts you to jack the drive wheel off the floor and to open the Emergency Lowering Valve. The Operator Display shows the test number and its results. To return to the Output menu, press the left or right button. Refer to “Output Tests” on page 6-127.
Wire Guidance Wire Guidance Maintenance Mode can be used to examine system tracking (Tracking Values), view individual antenna coil inputs (Coil Values), and clear the EEPROM on the Guidance Manager card (Clear WG EEPROM). The system can function at several different frequencies and strengths. The Wire Guidance floor signal strength must be consistent throughout the warehouse. Refer to Publication PDSS-0051 for floor adjustment, troubleshooting, and additional information. Tracking Values Use Tracking Values to monitor the Wire Guidance calculated position and record Tractor-First (TF) and Forks-First (FF) position values. When centered over the wire, near-wire coil signal strength is typically about 100%.
