Model 9600/9700 Swing-Reach ® Lift Truck
Section 3. Systems Overview Modes of Operation
CONFIGURE MODE MENU (TM S/W V3.5;CM S/W V2.9) Can be entered with Password unless Superword is specified Menu
Item
Selection
Password 1_______ (factory setting)
PassWord
Superwrd (Superword only)
2_______ (factory setting)
Elec Key 3_ _ _ _ _ _ _ (factory setting) Mnt Mind Enab\Dis
Disable Enable
Reset
Enter New Password Display Current Password Enter New Superword Display Current Superword Enter New Electronic Keys (up to 20) - enabled with FlashWare Display Current Elec Key Set parameters for Maintenance Minder Turn Maintenance Minder ON/OFF Reset #hours (deadman) until next reminder
Setup
300 Hrs (default) Msg Only (default)
Time
HH:MM:SS –AM –PM MM/DD/YY Disable Enable
Clock
Date 24-Hour
Description
Set #hours between reminders Choose between Lift CutOut or Message Only For more information, refer to “Maintenance Minder ™ Tool” on page 4-3) Set Time/Date Set time of day (AM or PM)
Set date Turn 24 hour clock ON/OFF
Auto Off
Disable (default) 10 Min 5 Min 4 Min 3 Min 2 Min 1 Min
Set idle time for automatic shut-off. Truck turns off after the programmed setting with no activity while off the deadman.
ActMaint (Superword only)
Enable Disable (default)
Set Active Maintenance
Brighten
Up Down Default
Set brightness of Operator Display
Publication: 1089040, Issued: 08 Apr 2016
3-19
