Model 9600/9700 Swing-Reach ® Lift Truck
Section 8. Theory of Operation Pinout Matrix
Function Description
Voltage Source
Voltage User
TM
Mini Lift Pressure Transducer
TM
Custom In T2
TM
S46A/B
B– to the optional End-of-Aisle Sensor (S47B) at S47B-8. It is then routed through the switch module to S46B-7 to S46A-8. It is connected on the TM through Fuse FU13 to JPS14-3 and 4, and on to TP4. There is no harness wiring connected at this point.
TM
S47A/B
B– for the Main Lift Pressure transducer.
Measure B+ at TP1 to verify connections. B– for the Load Handler Motor Temp Sensor. Then check for <0.5V wrt TP4.
TM
Main Lift Pressure transducer
TM
Load Handler Temp Sensor
VMIDO
Jumper used to identify module as the TM.
<0.5V
TM
TM
JPT24-17
SENSOR 2
Input voltage to the TM. It is generated by either S47A or S47B when one or both of them detect the presence of a floor magnet. SENSOR 2 is used along with SENSOR 1 (JPT12-10) to determine if the truck is in or out of the aisle. This information is used to control travel speed based on truck location and the position of the AUTO/MAN switch.
Magnet not sensed: >4V Magnet sensed: <1V
S47A/B
TM
220
JPT24-18
MAIN LIFT PRESS.
Analog DC voltage that varies directly with the weight on the carriage. Approx. 1V per 1000 lb. (453 kg). It is necessary to have the TM supply approx. 12V as well as DGND in order for the transducer to function correctly.
Forks Fully Lowered: 1V
Main Lift Pressure Transducer
TM
221
JPT24-19
MINI LIFT PRESS.
Analog DC voltage that varies directly with the weight on the mini-mast. Approx. 1V per 1000 lb. (453 kg). It is necessary to have the TM supply approx. 12V as well as DGND in order for the transducer to function correctly.
Forks Fully Lowered: 1V
Mini Lift Pressure Transducer
TM
222
JPT24-20
BATTERY GATE RT
Input voltage to the TM from the optional Battery Gate Prox 2 (S58). The proximity switch is used to detect the right battery gate is correctly installed. Travel is inhibited when the switch does not detect a correctly installed gate.
Gate installed: <1V Not installed: >4V
S58
TM
Item
Connection
Theory of Operations
212
JPT24-6
DGND
B– for Mini Lift Pressure Transducer.
213
JPT24-7
DGND
B– for Custom In T2.
214
JPT24-8
DGND
B– to the optional End-of-Aisle Sensor (S46B) at S46B-8. It is then routed through the switch module to S46B-7 to S46A-8.
215
JPT24-9
DGND
216
JPT24-10
DGND
217
JPT24-11
DGND
218
JPT24-16
219
