Model 9600/9700 Swing-Reach ® Lift Truck
Section 8. Theory of Operation Pinout Matrix Function Description
Voltage Source
Voltage User
Sensor plugged in: approx. 8V Sensor unplugged: 10 to 13V
TM
S47A/B
This is a custom input to the TM. Used for special optional inputs. When this is used, the ability to disable lift and reduce travel speed is possible.
Open: >4V Closed: <1V
Opt. Device
TM
DGND
B– for the Steer Motor Encoder.
Measure B+ at TP1 to verify connections. Then check for <0.5V wrt TP4.
TM
Steer Motor Encoder
JPT10-10
BUS1 +
Positive component of the digital communications between the TM and CM.
2.3V
TM
TM, CM
159
JPT12-5
LIFT
Lift/Lower Pendant connection to raise platform.
Lifting: <1V At rest: approx. 5V
Pendant
TM
160
JPT12-6
LOWER
Lift/Lower Pendant connection to lower platform.
Lowering: <1V At rest: >4V
Pendant
TM
161
JPT12-10
SENSOR 1
Input voltage to the TM from aisle detect sensor S46A. It is generated by either S46A or B when one or both sensors detect a floor magnet. Sensor 1 is used along with Sensor 2 (JPT24-17) to determine if the truck is in or out of the aisle. This information is used to control travel speed based on truck location and position of the AUTO/MAN switch.
Magnet not sensed: >4V Magnet sensed: <1V
S46A/B
TM
162
JPT12-12
DGND
B– for Lift/Lower Pendant.
Pendant
TM
163
JPT14-1
B–F
This connects B–F on the TM to TP4 (B–) through FU6 on the Fuse/Relay Card. These B– provide the return for everything not using DGND or AGND as reference.
Fuse/Relay Card
TM
Fuse/Relay Card
TM
TM
CM
Item
Connection
Theory of Operations
155
JPT10-7
+12V_SENSOR 2
12V to the optional End-of-Aisle Sensor (S47A) at S47A-3. It is then routed through the switch module to S47A-4 to S47B-3 to power that switch module also. There is also a circuit detect to verify the end-of-aisle sensor is connected. This voltage is present when the Key switch (S1) is ON.
156
JPT10-8
CUSTOM IN 3
157
JPT10-9
158
164
JPT14-2
DGND
This connects DGND on the TM to TP4 (B–) through FU6 on the Fuse/Relay Card. This is the reference for all circuits on the truck that reference DGND.
165
JPT14-3
DGND
B– for the Brake Deadman switch (S2). It is also used as a shield to the BUS communications.
8-30
Normal Level
Measure B+ at TP1 to verify connections. Then check for <0.5V wrt TP4.
