Section 8. Theory of Operation
Model 9600/9700 Swing-Reach ® Lift Truck
Pinout Matrix Function Description
Voltage Source
Voltage User
Deadman Up: >4V Down: <1V
S9
CM
SIDEGATE RIGHT Input voltage to the CM from the optional Right Sidegate switch (S60). The CM uses this voltage to determine whether the sidegate is raised or lowered. S60 is closed when the right sidegate is down.
Sidegate Up: >4V Down: <1V
S60
CM
JPC22-5
CHA-E1
Part of the steering request when the encoder is rotated. It is a square wave signal identical to CHB-E1 but different phase. The TM uses the phase relationship of the two channels to determine whether CW or CCW steering is requested. The number of pulses is used to determine the total movement requested.
Moving: approx. 2.5V Not Moving: <1V or 4.75V
Steering Encoder
CM
60
JPC22-6
SIDEGATE LEFT
Input voltage to the CM from the optional Left Sidegate switch (S61). The CM uses this voltage to determine whether the sidegate is raised or lowered. S61 is closed when the right sidegate down.
Sidegate Up: >4V Down: <1V
S61
CM
61
JPC22-7
CARRIAGE DEADMAN
Input voltage to the CM from the Carriage Deadman switch (S23). The CM uses this voltage to determine the state of S23. The TM and CM both use this information in conjunction with a travel request to release the brake; however, either cause the brake to apply when it detects a fault, regardless of deadman switch position.
Deadman Up: >4V Down: <1V
S23
CM
62
JPC22-9
HEIGHT PROX A
Input voltage to the CM from Channel A of the Mini Height Prox Sensor. It switches ON and OFF as it passes over the mini height sensing rail.
Not over metal: >1.7V Over metal: <0.7V
Mini Height Prox
CM
63
JPC22-10
HEIGHT PROX B
Input voltage to the CM from Channel B of the Mini Height Prox Sensor. It switches ON and OFF as it passes over the mini height sensing rail.
Not over metal: >1.7V Over metal: <0.7V
Mini Height Prox
CM
64
JPC22-11
DGND
B– for the Carriage Deadman switch (S23).
Measure B+ at TP1 to verify connections. Then check for <0.5V wrt TP4.
CM
S23
Item
Connection
57
JPC22-2
LOAD HANDLER DEADMAN
Input voltage to the CM from the Load Handler Deadman switch (S9). The CM uses this voltage to determine the state of S9. When S9 is detected closed (left deadman pedal pressed), the CM enables the use of the Mini-Mast and Load Handler functions. These functions are inhibited if S9 is detected open (left deadman pedal up).
58
JPC22-4
59
