Section 8. Theory of Operation
Model 9600/9700 Swing-Reach ® Lift Truck
Pinout Matrix Function Description
Voltage Source
Voltage User
S7
CM
Attachment switch (S5) input to the CM.
S5
CM
AUTO/MANUAL
AUTO/MAN switch (S4) input to the CM. Activates/deactivates guidance mode (wire or rail). Guidance Mode is activated when S4 is open and off when it is closed.
S4
CM
JPC12-12
DGND
B– for the Horn switch (S3), AUTO/MAN switch (S4), Attachment switch (S5), L/L Pot (VR2), and Travel Pot (VR1).
<0.5V
CM
S3, S4, S5, VR1, VR2
25
JPC14-2
DGND
B– for the Display Interface Card.
Measure B+ at TP1 to verify connections. Then check for <0.3V wrt TP4.
CM
Display Interface Card
26
JPC14-4
BUS1–
CAN Communication line between TM, CM, and Display Interface Card.
2.3V
Display Interface Card, CM, TM
Display Interface Card, CM, TM
27
JPC14-5
+12VD
+12V supply to Display Interface Card. Protected by an internal diode in the CM.
10.1 to 13V
CM
Display Interface Card
28
JPC14-7
B+K2
B+K2 supplied from the OTM Cable and the K2 energized: Fuse/Relay Card when the TM has B+ activated the K2 relay via the relay enable circuit. It provides B+ to SOL7, SOL8, SOL9A/B, and SOL10A/B. It also provides a return path for the suppressors to the coils.
Fuse/Relay Card
SOL7, SOL8, SOL9A/B, SOL10A/B
Item
Connection
21
JPC12-8
L/L_INH_ BYPASS
Lift/Lower Inhibit Bypass switch (S7) input to the CM. The voltage on this line determines whether the TM allows lift or lower when the specified Lift or Lower Limit height is reached. When this option is installed, S7 operation may be enabled or disabled in Configure Mode. With S7 open (not pressed), Main Lift/Lower beyond the specified height limit is inhibited. With S6 closed (pressed), further lifting or lowering is allowed.
22
JPC12-9
ATTACHMENT
23
JPC12-11
24
8-18
Theory of Operations
Normal Level Open: >4V Closed: <1V
