Model 9600/9700 Swing-Reach ® Lift Truck
Section 3. Systems Overview Modes of Operation enabled, the operator is prompted to enter his/her electronic key when the key switch is turned ON. Truck operation is not allowed unless the correct electronic key or Superword is entered.
Password Password permits access to Configure Mode only. It is intended for customer use in setting performance parameters within those features purchased with the lift truck.
Superword Superword permits access to all Program Modes. Superword is intended to limit service access to qualified and trained service technicians. We strongly recommend that, during installation, you change the Superword from the factory default to a code known only to the Sales and Service Center and/or owner so that access to Diagnostic Mode is limited to qualified personnel. Make sure to record the new Superword in a safe place. If this code is lost or forgotten, a technician must reset the lift truck to factory default settings. This makes it necessary to reconfigure all variable settings.
•
A traction system shutdown - travel is not allowed. Lift, lower, steering, and horn functions operate normally.
•
A shutdown in the lift/lower system - lift and lower are not allowed. Travel, horn, and steering functions operate normally.
•
Load Handler shutdown
Tone 4. A continuous tone with deadman pedal pressed and Auto/Manual switch in Manual indicates the truck is over the guide wire. Tone 5. Tone ramps up then repeats, indicating the truck is seeking and aligning over the guide wire. The tone continues until the truck is locked on the guide wire or the Auto/Manual switch is changed to Manual. Tone 6. Descending tone (bomb drop) that indicates an incorrect Password or Electronic Operator Key was entered. The tones described do not repeat continuously. A fault code and associated message scroll across the Operator's Display. The message repeats continuously until the key switch is turned OFF.
Using Program Mode
Run Mode Tones Tone 1. A single tone that indicates: •
A key on the Operator Keypad (Up/Down/Left/Right/Enter) is pressed
•
Maximum steer request is reached
Tone 2. Two tones (high/low) that indicate the TPC and LPC contactors are disabled (opened). Travel, steering, and lift/lower are disabled and the brake is applied until the problem is corrected. Tone 3. Three tones (high/medium/low) that indicate: •
3-12
A travel performance limitation - travel speed is limited to 1 mph (1.6 km/h). Lift, lower, steering, and horn functions operate normally.
By entering Program Mode, safety circuits associated with the ACR System are disabled. Follow all instructions in this manual for each test. If you are unsure how to conduct a test while in Program Mode, STOP: do not proceed with the test. Contact an authorized Raymond Sales and Service Center. To enter Program Mode, use the right button to obtain the cursor prompt. Using the up/down buttons to scroll to the desired number and the left/right buttons to move to a different character position, enter the Password or Superword, then press Enter.
Publication: 1089040, Issued: 08 Apr 2016
