Model 9600/9700 Swing-Reach ® Lift Truck
Section 3. Systems Overview Modes of Operation
Modes of Operation Overview of Modes
Version The version of software installed in the following devices is displayed: •
CM - Carriage Manager software
•
CMB - Carriage Manager Boot Block***
•
TM - Tractor Manager software
•
TMB - Tractor Manager Boot Block***
•
GM - Guidance Manager*
•
PAT - Traction Power Amp software
Run Mode
•
PATB - Traction Power Amp Boot Block***
•
PATVCL - Traction Power Amp VCL**
When you power the lift truck on normally, the on-board firmware performs a number of internal self-tests and enters the default mode of operation, Run Mode. Run Mode is the normal working mode. In Run Mode, the Operator Display shows the default display.
•
PAL - Lift Power Amp software
•
PALB - Lift Power Amp Boot Block***
•
PALVCL - Lift Power Amp VCL**
This lift truck has several modes of operation. The main distinction is between Run Mode and Program Mode. Run Mode is the normal working mode for the lift truck. Program Mode permits configuration, calibration, and diagnostic testing.
Program Mode Use Program Mode for configuration, calibration, and diagnostic testing on the lift truck. You need a password in order to enter Program Mode. See “Passwords” on page 3-11. Program Mode is divided into six categories: •
Serial #
•
Version
•
Hr Mtrs
•
Config
•
Learn (Superword required)
•
Maint (Superword required)
When Program Mode is exited, the electronic key prompt is displayed (if enabled) or the truck performs SelfTest and enters Run Mode.
*Guidance Manager change requires firmware chip to be replaced to change version. **VCL = Vehicle Control Language. This is Raymond specific software for the amp. ***Boot Block software cannot be changed in the field. NOTE: When using FlashWare, the amp VCL file and software are located in the same file.
Hour Meters and Distance Indicator The Operator Display shows the following accumulated totals: •
KH: Total hours the key switch has been turned ON
•
HD: Total hours on deadman
•
HL: Total hours spent lifting and lowering
•
TM: Total distance traveled (miles or kilometers, depending on Units specified in Config)
•
HT: Total hours spent traveling
•
HA: Total hours on Load Handler (traverse and rotate)
Serial # The serial number displayed must match the serial number on the tractor and mast specification tags. This field cannot be changed from Program Mode.
3-10
Publication: 1089040, Issued: 08 Apr 2016
