Section 7. Component Procedures
Model 9600/9700 Swing-Reach ® Lift Truck
Flow Limiters
Hydraulic Components
Flow Limiters
Removal
Main Mast Removal 1. Elevate the carriage approx. 3 ft. (1 m). Block and clamp between edge of carriage and baseleg. See “Blocking the Carriage” and Figure 2-6 on page 2-10. 2. Turn the key switch OFF and disconnect the battery connector. 3. Place a drain pan beneath the main lift cylinder hydraulic fitting. 4. Remove the hydraulic hose. Remove the flow limiter fitting. Figure 7-97.
Mini-Mast 1. Elevate the load handler approx. 3 ft. (1 m). Block and clamp the load handler. See “Blocking Load Handler” and Figure 2-7 on page 2-10. 2. Turn the key switch OFF and disconnect the battery connector. 3. Place a drain pan beneath the mini-mast lift cylinder hydraulic fitting. 4. Remove the hydraulic hose. Remove the flow limiter fitting. Figure 7-98.
Flow Limiter, Mini-Mast Lift Cylinder
Flow Limiters, Main Lift Cylinder
Lift Cylinder
Lift Cylinders Flow Limiter Fittings
Installation 1. Insert the new flow limiter fitting. 2. Install the hydraulic fitting and hose. 3. Reconnect the battery connector and turn the key switch ON. 4. Lift the carriage, remove the blocking, then lower the carriage completely. 5. Bleed the lift system as necessary. See “Bleeding the Hydraulic System” on page 7-74. 6. Check hydraulic fluid level.
Flow Limiter Fitting
Installation 1. Insert the new flow limiter fitting. 2. Install the hydraulic fitting and hose. 3. Reconnect the battery connector and turn the key switch ON. 4. Lift the load handler, remove the blocking, then lower the load handler completely.
7-84
Publication: 1089040, Issued: 08 Apr 2016
