Section 7. Component Procedures
Model 9600/9700 Swing-Reach ® Lift Truck
Motors
Electrical Components
Motors
DC Motor Service Motor Brushes
General
Inspection
Power Cable Terminals Table 7-5.
Figure 7-66.
Motor Brush Location
Power Cable Terminal Torques
Location/Stud Size/Type Traction Motor Lift Motor
Torque Top Nut: 17 to 18.4 ft. lb. (23 to 25 Nm) Bottom Nut: 10.7 to 11 ft. lb. (14.5 to 15 Nm)
Load Handler Motor
Top Nut: 8.2 to 10 ft. lb. (11.2 to 13.6 Nm) Bottom Nut: 11.6 to 13.3 ft. lb. (15.8 to 18.1 Nm)
Steer Motor
1.4 ft. lb. (1.9 Nm)
Power Amplifiers
8 to 8.6 ft. lb. (11 to 11.6 Nm)
Contactor - M6 steel
4.2 ft. lb. (5.7 Nm)
Contactor - M8 steel
15 ft. lb. (20.3 Nm)
Contactor - M8 brass/copper
5.7 ft. lb. (7.8 Nm)
DC Motor Troubleshooting See “DC Motors” on page 5-15.
AC Motor Troubleshooting See “AC Motors” on page 5-20.
Conduct a partial inspection of the motor during scheduled maintenance. If the truck is operated in a severe or caustic environment or is used in an extended duty cycle application, inspect the motor more frequently. Set up and rigidly adhere to a strict inspection schedule to obtain the maximum efficiency from the electrical equipment. Each partial inspection of the motor must include: 1. Inspect the brushes for wear and for correct contact with the commutator. Record the level of wear on the brushes. This history provides an indication of whether a brush must be changed or if it can wait until the next inspection. Refer to Table 7-6 on page 7-54 for acceptable brush length. NOTE: Overloading a unit is ultimately reflected in the motor and brush wear; therefore, you must take this into account when considering brush replacement.
