Model 9600/9700 Swing-Reach ® Lift Truck Electrical Components Figure 7-63.
Section 7. Component Procedures Wiring and Harness Connectors
Wedge Lock Flush With Housing
Testing Do not pierce wire insulation with a sharp point while troubleshooting. The wedge lock has slotted openings in the forward (mating) end. These slots accommodate circuit test tabs that are approx. 3.3 by 0.6 mm, that prevent damage to the receptacle. For circuit testing in the field, use a flat probe such as a pocket knife blade. Do not use a probe with a sharp point.
Publication: 1089040, Issued: 08 Apr 2016
7-49
