Model 9600/9700 Swing-Reach ® Lift Truck Test I105 – Mini Ht Ct [Mini-Mast Height Count]
Section 6. Electrical Tests Input Tests
Test I105 – Mini Ht Ct [Mini-Mast Height Count] The mini-mast height count, calculated by the TM, is displayed. The displayed height should increase during lift and decrease during lower. The mini-mast height count is determined by the height proximity sensor inputs. When the mini-mast is fully lowered, Height Prox A (“Test I106 – Mini Sw A [Mini-Mast Height Prox A]”), Height Prox B (“Test I107 – Mini Sw B [Mini-Mast Height Prox B]”), and Height Prox C (“Test I108 – Mini Sw C [Mini-Mast Height Prox C]”) are all ON. While lifting or lowering, if all three inputs are present at the same time, a fault code occurs. Also, if one of the inputs does not change state while lifting or lowering, a fault code occurs. Navigate to the input menu and scroll until I06, I07, and I08 are all displayed. Observe the status of each input while lifting or lowering. If one of the inputs remains ON, it may indicate a shorted mast cable or wiring. If one of the three inputs does not change from ON to OFF while lifting/lowering, refer to the input for the switch that is not changing state.
Publication: 1089040, Issued: 08 Apr 2016
6-111
