Model 9600/9700 Swing-Reach ® Lift Truck
Section 6. Electrical Tests Analog Tests
Test A22 – Thrtl % [Travel Request]
Test A22 – Thrtl % [Travel Request] The percentage of throttle request the TM sends to the TPA is displayed. This value is based on VR1 position as calculated by the TM. NOTE: Run Learn after you replace, repair, or adjust the throttle pot. Refer to Learn Controls on page 3-22. The test is good if the value displayed is within these limits: Throttle Position
Percentage Displayed
Full TF
0 to +100
Neutral
0
Full FF
0 to –100
The values should change smoothly and evenly as the handle moves from Full Tractor-First to Full Forks-First. If these results are not observed, refer to Diagnosis and Repair.
Diagnosis and Repair Refer to Test A04 – Thrtl Pot [Throttle Pot (VR1)] (page 6-40). Compare Test A04 with Test A22. Maximum throw should show maximum values. If so, replace the TPA. If not, check traction system for speed limitations due to motor temperature, limit switches, or configured speed.
6-54
Publication: 1089040, Issued: 08 Apr 2016
