JLG T350 T500J Parts Manual (3121199)_english

SECTION 1 - FRAME FIGURE 1-19. DRIVE DIRECTIONAL VALVE ASSEMBLY (USED WITH DRIVE OPTION ONLY) ITEM 1 1 2 2 3 3 4 4 4 5

3121199

PART NUMBER 4641420 70002815 Not Required 7024898 7012518 7010542 7010543 7024899 7017402 7024885 See Note

QTY Ref 4 0 2 2 3 3 2 2 4 2

DESCRIPTION DRIVE DIRECTIONAL VALVE ASSEMBLY Cartridge, Counterbalance Valve Seal Kit - Cartridge Cartridge, Valve Seal Kit - 7024898 Cartridge Cartridge, Load Sensing Valve Seal Kit - 7010542 Cartridge Cartridge, Solenoid Cartridge Seal Kit - Cartridge Coil Orifice (.40) (Not Shown) (Note: Not available for purchase)

T350/T500J

REV B

69
