FIGURE 2 6. TURNTABLE MOUNTED COMPONENTS (STROBE LIGHT, ALARM AND ACCESSORY TRAY
FIGURE 2-6. TURNTABLE MOUNTED COMPONENTS (STROBE LIGHT, ALARM AND ACCESSORY TRAY)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref MOTION ALARM AND STROBE LIGHT INSTALLATION
(OPTIONAL)
Ref Motion Alarm and Strobe Options: 0273669 Ref Motion Alarm and Strobe Light Option F 0275048 Ref Motion Alarm Option (SN 0030000281 through 0030012032) D 0275030 Ref Strobe Light Option (SN 0030000281 through 0030012032) D 1 0140043 1 Alarm 2 0700412 2 Bolt 4mm x 25mm 3 0700610 2 Bolt 6mm x 20mm 4 0701014 2 Bolt 10mm x 30mm 5 0903087 1 Bracket, Mounting 6 2920161 1 Strobe Light Assembly 6 7016319 1 Bulb 6 7016372 1 Lens 7 3290405 2 Locknut 4mm 8 3290605 2 Locknut 6mm 9 3291005 2 Locknut 10mm 10 4060865 1 Guard, Strobe 11 4811400 2 Flatwasher 4mm 12 4811700 6 Flatwasher 6mm 13 4812000 4 Flatwasher 10mm 14 4923128 1 Harness, Strobe/Alarm (Not Shown - See ELECTRICAL SECTION for Breakdown) 0274290 Ref ACCESSORY TRAY INSTALLATION (OPTIONAL) C 101 0641610 4 Bolt 3/8in-16NC x 1-1/2in (Use p/n 0641612) 102 3311605 4 Locknut 3/8in-16NC 103 Ref Mount, Accessory Tray Options: 103 4340929 1 Mount, Accessory Tray (Use p/n 1001092449) (Prior to SN
0030002110)
103 4341400 1 Mount, Accessory Tray (SN 0030002110 through 0030012032) 104 4711600 8 Flatwasher, 3/8in Hardened (Use p/n 4891600)
