FIGURE 1 20. DRIVE MOTOR ASSEMBLY (USED WITH DRIVE OPTION ONLY
FIGURE 1-20. DRIVE MOTOR ASSEMBLY (USED WITH DRIVE OPTION ONLY)
ITEM PART NUMBER QTY
DESCRIPTION
Ref DRIVE MOTOR ASSEMBLY 3160319 Ref Drive Motor Assembly (Prior to SN 0030001055) 3160327 Ref Drive Motor Assembly (SN 0030001055 through 0030012032) 1 Ref Bolt Options: 1 7023329 7 3160319 Motor (Prior to SN 0030001055) 1 70000287 7 3160327 Motor (SN 0030001055 through 0030012032) 2 7023328 1 Cover 3 7023412 1 Seal, Commutator 4 7023412 5 Ring, Seal 5 7023315 1 Commutator (Includes Item 6) 6 7023315 1 Ring, Commutator (Includes Item 5) 7 70000277 1 Manifold 8 Ref Rotor Set Options: 8 70000278 1 3160319 Motor (Prior to SN 0030001055) 8 70000288 1 3160327 Motor (SN 0030001055 through 0030012032) 9 7023311 1 Plate, Wear 10 Ref Link, Drive Options: 10 70000279 1 3160319 Motor (Prior to SN 0030001055) 10 See Note 1 3160327 Motor (Note: Not Available - Purchase Complete Drive Motor p/n 3160327) (SN 0030001055 through 0030012032) 11 7023308 1 Bearing, Thrust 12 70000281 1 Shaft 12A 70000282 1 Key, Shaft 12C 70000283 1 Washer, Shaft 12D 70000284 1 Bolt, Shaft 12E 70000285 1 Lockwasher, Shaft 12F 70000286 1 Ring, Shaft Retaining 13 7023405 1 Bearing, Inner 14 7023406 2 Thrustwasher 15 7023407 1 Bearing, Thrust 16 7023412 1 Seal 17 7023412 1 Washer, Backup 18 70000280 1 Housing 19 7023408 1 Bearing, Outer 20 7023412 Seal, Dirt and Water 25 7023412 1 Washer, Backup 26 7023412 1 Seal Kit (Includes Items 3, 4 16, 17 & 25)
