FIGURE 3 4. MAIN BOOM ASSEMBLY (T500J
FIGURE 3-4. MAIN BOOM ASSEMBLY (T500J)
ITEM PART NUMBER QTY
DESCRIPTION
Ref BOOM ASSEMBLIES (T500J) 0801423 Ref With and Without Air and Water Lines to Platform 1001114582 Ref With Air and Dual Water Lines to Platform 1 0100011 AR Compound, Locking 2 3900316 8 Screw 3/8in-16NC x 1in 5 0641607 2 Bolt 3/8in-16NC x 7/8in 6 Ref Bolt Options: 6 0641628 2 Bolt 3/8in-16NC x 3-1/2in 6 0641634 2 Bolt 3/8in-16NC x 4-1/4in 7 0641830 4 Bolt 1/2in-13NC x 3-3/4in 8 Ref Base, Boom Options: 8 0801424 1 With and Without Air and Water Lines to Platform 8 1001114587 1 With Air and Dual Water Lines to Platform 8A 0961948 2 Bushing 9 Ref Fly, Boom Options: 9 0801425 1 With and Without Air and Water Lines to Platform 9 1001114588 1 With Air and Dual Water Lines to Platform 9A 0962292 2 Bushing 10 0811607 22 Screw 3/8in-16NC x 7/8in 11 0811608 2 Screw 3/8in-16NC x 1in 12 Ref Powertrack Options: 12 1180393 1 With and Without Air and Water Lines to Platform 12 Ref With Air and Dual Water Lines to Platform 12 1001114586 1 Powertrack (Prior to SN 0030008195) 12 1001224893 1 Powertrack (SN 0030008195 through 0030012032) 12 Ref Repair Section Options: 12 70002233 1 With and Without Air and Water Lines to Platform 12 70002532 1 With Air and Dual Water Lines to Platform 13 Ref Tube, Push Options: 13 Ref With and Without Air and Water Lines to Platform 13 1180395 1 Tube, Push (Prior to SN 0030000460) 13 1180398 1 Tube, Push (SN 0030000460 through 0030012032) 13 1001114589 1 With Air and Dual Water Lines to Platform 14 1684397 1 Platform Level Cylinder Assembly (See CYLINDER SECTION for Breakdown) 15 1684402 1 Telescope Cylinder Assembly (See CYLINDER SECTION for Breakdown) 18 3311605 10 Locknut 3/8in-16NC 19 Ref Pad Options: 19 Ref With and Without Air and Water Lines to Platform 19 3340764 1 Pad (Prior to SN 0030000460) 19 4220254 1 Pad (SN 0030000460 through 0030012032) 19 1001114667 1 With Air and Dual Water Lines to Platform 20 3340881 10 Pad, Wear 21 3422745 1 Pin 22 3423105 2 Pin 23 3423161 2 Pin 24 Ref Plate Options: 24 Ref With and Without Air and Water Lines to Platform 24 3538758 1 Plate (Prior to SN 0030000460)
REV
O E
ITEM PART NUMBER QTY
DESCRIPTION
24 3575889 1 Plate (SN 0030000460 through 0030012032) 24 1001114670 1 With Air and Dual Water Lines to Platform 26 3760115 4 Ring, Retaining 27 3760351 4 Ring, Retaining 28 3841143 2 Keeper, Pin 29 4070897 10 Shim 18 Gauge 30 4070898 10 Shim #11 Gauge 31 4071039 2 Shim 18 Gauge 32 4071040 2 Shim #11 Gauge 33 3900283 2 Screw 3/8in-16NC x 3/4in 34 4630004 1 Pivot 35 Ref Pad, Wear Options: 35 4700017 1 With and Without Air and Water Lines to Platform 35 1001114756 1 With Air and Dual Water Lines to Platform 36 Ref Pad, Wear Options: 36 4700018 1 With and Without Air and Water Lines to Platform 36 1001114755 1 With Air and Dual Water Lines to Platform 37 4700019 2 Pad, Wear 39 4711600 18 Flatwasher 3/8in Thin 40 4891800 4 Flatwasher 1/2in Hardened 41 4071117 1 Shim (SN 0030001367 through 0030012032)
