FIGURE 1 13. PARKING BRAKE CABLE (ANSI, ANSI EXPORT AND AUSTRALIAN SPEC MACHINES ONLY) AND TRANSPORT LOCK ASSEMBLIES
FIGURE 1-13. PARKING BRAKE CABLE (ANSI, ANSI EXPORT AND AUSTRALIAN SPEC MACHINES ONLY) AND TRANSPORT LOCK ASSEMBLIES
ITEM PART NUMBER QTY DESCRIPTION REV
Ref PARKING BRAKE CABLE ASSEMBLIES (ANSI AND ANSI
EXPORT SPEC MACHINES ONLY)
Ref Note: For CE Spec Components, See Axle and Tongue
Installation or Hydraulic Brake Assembly.
3890043 Ref Parking Brake Cable Assemblies T350 with Electric Brakes B 3890041 Ref Parking Brake Cable Assemblies T350 with Hydraulic Brakes B 3890044 Ref Parking Brake Cable Assemblies T500J with Electric Brakes C 3890042 Ref Parking Brake Cable Assemblies T500J with Hydraulic Brakes C 1 2980123 1 Handle Assembly (No Serviceable Parts Available) 2 Ref Brake Cable Assembly - Tongue Options: 2 3890045 1 Brake Cable Assembly T350 2 3890046 1 Brake Cable Assembly T500J 3 Ref Brake Cable Assembly - Splitter to Wheels Options: 3 3890049 1 Brake Cable Assembly T350 with Electric Brakes B 3 3890047 1 Brake Cable Assembly T350 with Hydraulic Brakes B 3 3890050 1 Brake Cable Assembly T500J with Electric Brakes B 3 3890048 1 Brake Cable Assembly T500J with Hydraulic Brakes B 3A See Note 1 Splitter/ Equalizer (Note: Purchase Complete Brake Cable Assembly) 3B See Note 2 Cable, Brake (Note: Purchase Complete Brake Cable Assembly) 3C See Note 2 Pin (Note: Purchase Complete Brake Cable Assembly or Source Locally) Ref Note: See Axle and Tongue Installation for Additional
Hardware.
Ref TRANSPORT LOCK ASSEMBLY 0273627 Ref Transport Lock Assembly T350 E 0274395 Ref Transport Lock Assembly T500J B 101 Ref Bolt Options: 101 0641640 4 Bolt 3/8in-16NC x 5in (T350) 101 0641646 4 Bolt 3/8in-16NC x 5-3/4in (T500J) 102 0681506 6 Bolt 5/16in-18NC x 3/4in 103 2940159 1 Latch, Manual Clamp 104 3311605 4 Locknut 3/8in-16NC 105 3271505 6 Locknut 5/16in-18NC 106 3575420 1 Plate, Transport Lock 107 Ref Plate, Mounting Options: 107 3575719 1 Plate, Mounting T350 107 3575783 1 Plate, Mounting T500J 108 4751600 8 Flatwasher 3/8in Wide
