FIGURE 2 5. GROUND CONTROL BOX ASSEMBLY AND INSTALLATION
FIGURE 2-5. GROUND CONTROL BOX ASSEMBLY AND INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
0861648 Ref GROUND CONTROL BOX ASSEMBLY (COMMON PARTS) L 1 0140011 1 Alarm 2 0610170 1 PC Board 3 0861647 1 Box 4 1705971 1 Decal 5 2420172 1 Hourmeter 6 3575358 1 Plate, Switch Mounting 7 3900352 2 Screw, Button Head 5mm x 25mm 8 3900358 6 Screw, Button Head 6mm x 10mm 9 3960587 1 Seal 10 4060906 1 Guard, Switch 11 4220210 1 Block, PC Board Mounting 12 4360328 5 Switch, Toggle 13 4360330 1 Switch, Toggle 15 Ref Switch, Emergency Stop 15 4360475 1 Cap, Replacement 15 7020175 1 Block, Replacement Contact 15 7020176 1 Plate, Plug Mounting 16 3575623 1 Rivet 17 3820020 4 Flatwasher #10 Thin 18 4711000 4 Connector, Strain Relief 19 4460426 1 Connector, Strain Relief (Prior to SN 0030009593) 19 4460386 1 Connector, Strain Relief (SN 0030009593 through 0030011022) Ref GROUND CONTROL BOX ASSEMBLY (OPTIONAL PARTS) Ref Ground Control Box Assembly (Optional Parts) T350 Models 0861663 Ref Electric Powered Machines (ANSI and ANSI Export Specs) K 0861671 Ref Electric Powered Machines (CE and Australian Specs) H 0861661 Ref Gas Powered Machines (ANSI and ANSI Export Specs) K 0861672 Ref Gas Powered Machines (CE and Australian Specs) H Ref Ground Control Box Assembly (Optional Parts) T500J
Models
0861662 Ref Electric Powered Machines (ANSI and ANSI Export Specs) K 0861673 Ref Electric Powered Machines (CE and Australian Specs) H 0861649 Ref Gas Powered Machines (ANSI and ANSI Export Specs) (Prior J
to SN 0030011022)
0861674 Ref Gas Powered Machines (CE and Australian Specs) H 101 0861648 1 Common Ground Control Box Assembly (See Items for 1-19 for Breakdown) 102 Ref Components Options: 102 3520028 1 Plug, Hole (T350) 102 4360328 1 Switch, Toggle (Jib) (T500J) 103 Ref Components Options: 103 3520030 1 Plug, Hole (Electric Powered Machines) 103 4360564 1 Switch, Push Button (Black) (Gas Powered Machines) 104 Ref Components Options: 104 3520030 1 Plug, Hole (Electric Powered Machines) 104 4360565 1 Switch, Push Button (Yellow) (Gas Powered Machines) 105 Ref Harness Options (Not Shown - See ELECTRICAL SECTION for Breakdown): 105 4923118 1 Electric Powered Machines
ITEM PART NUMBER QTY DESCRIPTION REV
105 4923125 1 Gas Powered Machines 106 Ref Keyswitch Options: 106 4360469 1 ANSI and ANSI Export Specs 106 4360470 1 CE and Australian Specs 106A 2860030 1 Set Key, Replacement Ref GROUND CONTROL BOX INSTALLATION Ref Ground Control Box Installation T350 Models 0273615 Ref Electric Powered Machines (ANSI, ANSI Export and South
Africa Specs)
B
0274111 Ref Electric Powered Machines (CE and Australian Specs) B 0273960 Ref Gas Powered Machines (ANSI, ANSI Export and South Africa B 0274112 Ref Gas Powered Machines (CE and Australian Specs) B Ref Ground Control Box Installation T500J Models 0273961 Ref Electric Powered Machines (ANSI, ANSI Export and South B
Africa Specs)
0274113 Ref Electric Powered Machines (CE and Australian Specs) B 0273962 Ref Gas Powered Machines (ANSI, ANSI Export and South Africa B 0274114 Ref Gas Powered Machines (CE and Australian Specs) B 201 0100035 AR Compound, Locking 202 0761012 4 Bolt 10mm x 25mm 204 4812000 4 Flatwasher 10mm 205 4240175 1 Tie-Strap (Not Shown - Located Beneath Ground Control Box)
