2009 Opel Astra H Service Manual - PDF DOWNLOAD

Page 95

Tires get old, even if the car does not drive or drives low. Unused spare wheel after 6 months to apply only in extreme cases and only at a slow ride. Never place used tires, whose origin is unknown. In order not to impair brake cooling, use only shields the wheels, admitted for this car. Winter tires Winter tires at a temperature below 7 "C provide improved safety, so they should be installed on all wheels. Summer tires in its construction have limited features for winter operation. If the maximum allowable speed for winter tires less than the car, attach the index plate with a permissible maximum speed of winter tires in a conspicuous place of the driver. NOTICE When use Reserve oscilla-sa with summer bus perhaps modification is running qualities car. Urgently replace damaged tire, otbalansiruyte wheel and US-establish, his on car. Caps wheels In the case of application is not approved by Opel caps wheels and tires need to pay attention to the fact that the tires had no protective thickening. Chains protivoskolzheniya The use of chains is allowed only on the leading wheels (front) of the bridge.

Fig. 1.244. Chains protivoskolzheniya Use melkozvennye chain, the height of which, together with a connecting link in the chain of running surface and the inside of the tire is a maximum of 15 mm. NOTE Caps steel wheels may Co-touch with links chains and damage-Xia. Before installation chains kolpa-ki wheels should removed. Snow chains are allowed to use only up to 50 km / h and at snowless areas only for a short time, since the solid surface, they quickly wear out and can burst. Emergency Wheel Use of snow chains on the emergency wheel is not allowed. If you puncture to the front wheel drive with snow chains, emergency wheel should be installed on the rear axle and rear wheel - on the front.

1.32 Start the engine by using an auxiliary start cable If the battery is discharged Opel Astra car, the engine can be run using the auxiliary start cable and battery of another car (Figure 1.245).

Fig. 1.245. Auxiliary starter cables It should exercise extreme caution. Any deviation from the instructions given may result in injury or damage in the explosion of battery battery and damage to electrical devices of both cars. Avoid sparks and open flame near the battery.

95
