If necessary, remove the trim at the top of the rear rack of the vehicle (C or D - depending on model). Gently pull down the ceiling panel upholstery and loosen the screws holding the hinge pin. NOTE Rear ceiling upholstery attached to Roof with help Velcro. Close the door and check the back of the uniformity of the gap between adjacent elements of the bodywork. The back of the door is adjusted correctly when in the closed position around the perimeter is a uniform gap, and the door is flush with the surrounding bodywork surfaces. If necessary, adjust gap is shifting back of the door in the appropriate direction. To adjust the depth of planting the back of the door in the doorway to release the rubber dampers. Turning to the clips on the angle from 60 to 80 ° counterclockwise. Then install the dampers on both sides so that the back of the door in the closed position freely adjoined to them. Note: To facilitate the adjustment apply to the doughy mass dampers - for a spot on the mass determine if adjacent door. After setting back the catch to its original position - Installation labels must coincide. Tighten the bolts fastening the hinge pin with the required effort. Replace the back of the bracket of the door and tighten its mounting screws by hand. Gently close the door to the back of: clamp will lock into position. Open the door and tighten the bolts fastening brackets with the required effort. Several times, close and open the door and make sure the back of the correctness of its control and correct functioning of the lock, if necessary, repeat adjustment. Check the back of the door trim.
7.14 Removal and installation of door lining the back of Open the back of the door, remove the shelf in trunk and remove the retention cables shelves of upholstery window frame. Enter under the upholstery of the frame window plastic wedge, press 4 release and separate the trim from the window frame first with one, and then on the other side (Figure 8.18).
Fig. 8.18. Withdrawal Upholstery frame windows Two-ri back of: 1 - upholstery frame window Remove the back of the pad lock the doors. Remove the clamp and remove the fixing screw in the frame of a door handle (Figure 8.19).
343
