Fig. 8.4. Mounting protection arch before-it Wheels - Arrow given spacing-WIDE rivets arch: 1 - mounting screws and 2 - protection of the arch Installation is performed in reverse order of removal.
7.7 Removing and installing the front bumper / bumper moldings Remove the decorative grille. Remove the mounting pads front bumper (see Figure 8.5). Release the temperature sensor of the holder on the grille bumper moldings.
Fig. 8.5. Mounting pads front bumper Car Opel Astra: 1,3 - bolts fastening; 2,4 - locks, 5 - lining With proper configuration, disconnect the wiring fog lamps, and headlamp washer hose from the tank with the liquid for washing of glass-Collect spilled liquid. Click on the side fasy bumper pads in the direction of up and release the pad from the side rails (see Figure 8.6).
335
