Fig. 7.30. Withdrawal Sensor - Switch castle Doors back of Installation is performed in reverse order of removal. Pay attention to the cabling.
6.30 Removal and installation of the loudspeaker Broadband speakers (front and rear) NOTE Loudspeakers enshrined in door assemblies. At models Astra GTC rear speakers fixed on sidewalls baggage th offices. To access the loudspeaker clear trim / finish of the corresponding door / sidewall.
Fig. 7.31. Mounting loudspeaker Remove the 3 mounting screws and remove the speaker, then disconnected the wiring harness connector (Figure 7.31). Installation is performed in reverse order of removal. Front tweeter Using a plastic wedge separate triangular pad the front door, remove the foam insert. Disconnected connector wiring Tweeter, press the latch and remove the speaker of the planting slot (Fig. 7.32).
330
