Fig. 3.27. Disconnecting Oprah Pedals: 1 - bolts, 2 - nut, 3 - nuts pedal Loosen the bolt pedal (Figure 3.26) Remove the pedal from the cross-pillar (Figure 3.27). On vehicles with left-hand steering unscrew the 2 screws fastening. On cars with right-hand-steering unscrew the nut fastening. Remove the support from the pedal clutch master cylinder by unscrewing 2 nuts (Figure 3.27). Slide back to the master cylinder clutch. NOTE Not damage the harnesses wires and attached elements. Remove the prop pedal carefully assembled with the clutch pedal. Setting Install prop pedal with clutch pedal. NOTE When Installation use new bolts. Attach the pedal to the crossbar support by tightening the 2 nuts mounting point 20 Nm. NOTE Use new nuts. Attach the clutch pedal to the clutch master cylinder. Attach the strap. NOTE Use new spud. Attach the return spring to the clutch pedal. Attach the control switch gears. Install the lower instrument panel pad. Install light switch and turn counterclockwise. Install the steering column shroud.
2.6 Clutch - Manual Transmission General Cars Opel Astra / Zafira equip 5 and b-speed manual gearboxes for all types of engines. All forward gears are equipped with synchronizers, gear ratios vary in each version of the engine. Corps gearboxes are made of aluminum or magnesium alloy.
125
