2.4 Transmission. Clutch - Removal and installation of piping and discharge hose coupling (gear - F13 / F17 / F17 + / F23 / M2O / M32) Remove Close the tank and disconnect the brake hydraulic supply line from the clutch master cylinder (Figure 3.16). Assemble arising brake fluid.
Fig. 3.15. Setting slave CD and stubborn plate: 1,3 - a special device KM-6263-30, 2 - mandrel
Fig. 3.16. Feeding pipeline and tank stopping hydraulic system: 1 - tank brake hydraulic system 2 - the supply line Close the tank hydraulic brake system of protective cap. Fill the tank hydraulic brake system up to the mark "MAX". Disconnect the mass wire from the battery, disconnect the positive wire from the battery. Remove the strap, loosen the bolt and remove the battery (Figure 3.17).
118
