Page 105

Remove the tire repair kit. Screw the hose to inflate tires to a free socket flasks with sealant. This prevents leakage of sealant. Remove the tire repair kit in the trunk. Remove speaking sealant with a rag. Fold the warning triangle and remove the trunk. Appended to the kit label the maximum available speed, which allowed to go after the repair tires. Attach the sticker in the driver's field of vision. Immediately proceed with a trip to the sealant evenly distributed within the tire. About 10 kilometers (not later than 10 minutes) stop and check the tire pressure. To do this, screw air compressor hose directly to the tire valve (see Fig. 1.272).

Fig. 1.272. Setup Compressor NOTE If pressure in bus than 1,3 bar, turn down his to setpoint. Repeat the process until such time as there is no fixed pressure loss. If the tire pressure has fallen below 1,3 bar, go on a car can not. Ask for help at service stations.

1.37 Motor Oil Level and flow of motor oil Rate oil consumption is possible only after a sufficiently long run, while in the initial period (during running) the level of expenditure may exceed the value specified in the documentation. Frequent driving at high engine speeds also leads to increased oil consumption.

Fig. 1.273. Masloizmeritelny probe Astra motor car Controlling the level of engine oil is carried out automatically. Before long trip is recommended to monitor the level of motor oil. Control level and refilling the engine oil Monitoring is performed only on the flat car and set off a hot engine. Before you check wait at least 5 minutes to oil, located in the lubricating circuit has had time to drain the oil pan. To check the oil level plug grated masloizmeritelny probe to the hard surface on the handle. Top up the oil, if its level dropped in the region mark refueling MIN (Fig. 1.274). The oil level should not exceed the upper mark MAX oil level gauge. Transfused oil drain or pump out. If the oil level exceeds the MAX mark, there is a risk of engine damage or a catalyst. Oil should be topped up with the same brand that was used in the previous oil change, observing the instructions in the service book. Position the plug and tighten it until it stops.

105
