Other Draining Oil from Hydraulic Oil Tank
AL
・ Keep away from fire. ・ Be sure to stop the engine before beginning work. Warning ・ The temperature of the hydraulic oil is high immediately after stopping the engine. Wait until the hydraulic oil temperature has decreased (to 40 ℃ or less) before beginning work.
Items to prepare
TE RN
• Wrenches (17 mm, 19 mm, 41 mm) • Feed pump (power source for feed pump) • Extension cable
• Cleaning fluid
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
[1] Press the air breather button (1) on top of the hydraulic oil tank to bleed off the pressure in the tank.
E
IN
• Waste oil tank • Waste oil can • Rag
[2] Use a wrench (17 mm) to remove the 6 bolts (2), and then remove the feed port cover (3).
407
WSM-13-19-005EN 3
