Other Assembly and Disassembly Section
SH700-5
Other Removal and Installation of Side Door Items to prepare • Wrench (19 mm)
AL
[1] Use a wrench (19 mm) to remove the 4 bolts (1) and 4 washers, and then remove the side door (left) (2).
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE RN
[2] Use a wrench (19 mm) to remove the 4 bolts (1) and 4 washers, and then remove the side door (left center) (3).
[3] Use the hexagon wrench to remove the 2 hexagon socket head bolts. Use a wrench (19 mm) to remove the 4 bolts (1) and 4 washers, and then remove the side door (left rear) (4).
405
WSM-13-19-005EN 1
