Procedures for Removal and Installation of Cab Inner and Outer Parts Removal and Installation of Cab Front Glass ・ Reinforced glass is used for the front window. Caution ・ Be extremely careful not to damage it when touching it during removal or installation.
AL
Items to prepare • Wrench (10 mm) • Rag
TE RN
• Cleaning fluid
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
[1] Use a wrench (10 mm) to remove the 2 bolts (1) each, and then remove the brackets (2) and (3).
[2] Remove the covers (4) and (5) for the bracket.
[3] Use a wrench (10 mm) to remove the 3 bolts (6), and then remove the front glass left lower bracket (7).
WSM-13-17-005EN
395 18
