Procedures for Removal and Installation of Cab Inner and Outer Parts Removal and Installation of Wiper Items to prepare • Wrench (17 mm) • Phillips screwdriver
AL
1. Removal of wiper
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE RN
[1] Use a wrench (17 mm) to remove the nut (1), and then remove the wiper arm (2).
[2] Use the Phillips screwdriver to remove the screw (3), and then remove the wiper (4).
2. Installation of wiper
To install, perform the reverse of the removal procedure.
WSM-13-17-005EN
387 10
