Remote Control Valve Removal and Installation of Travel Remote Control Valve Warning ・ Be sure to release hydraulic pressure before beginning work.
AL
Caution ・ Be sure to stop the engine before beginning work.
Items to prepare
TE RN
• Wrench (19 mm) • Box wrench (17 mm) • Hexagon wrench (8 mm)
IN
• Phillips screwdriver • Marking pen • Caps
E
• Plugs • Rag
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
• Cleaning fluid
1. Removal of travel remote control valve
[1] Remove the 3 screws (1) on the cover (2) and remove the cover.
[2] Remove the floor mat (3).
223
WSM-13-10-005EN 23
