Travel Unit [7] Removal of base plate (2-1) Loosen the hexagon socket head bolts (33) and remove the base plate (2-1).
TE RN IN E
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
• The base plate (2-1) is pushed upwards by the springs (26). For this reason, loosen the hexagon socket head bolts (33) evenly when loosening. • Positioning knock pins (27) are mounted between the base plate (2-1) and main unit. For this reason, pull the base plate (2-1) straight off in alignment with the center axis of the motor when removing it so that it does not become stuck with the knock pins (27). If it becomes stuck, lightly strike the base plate (2-1) with a plastic hammer to put the knock pins (27) in the correct position, and then remove the base plate (2-1). • When removing the base plate (2-1), the valve plate (5) is attached to the base plate (2-1). The valve plate (5) sliding surface is easily scratched, so be careful not to let the valve plate (5) fall.
AL
Caution: When removing the base plate (2-1), observe the following precautions.
[8] Removal of valve plate (5) Remove the valve plate (5) on the motor (cylinder block (4)). Caution: When removing the valve plate observe the following precaution.
(5),
• The cylinder block (4) and valve plate (5) sliding surfaces are easily scratched. If the sliding surface is scratched, prescribed capabilities will disappear, so prevent scratching from occurring.
28
WSM-13-02-005EN 23
