[2] Removal of spool assembly (2-2) Lightly press the end of the spool assembly (2-2) and eject one part of the spool assembly (2-2) out from the base plate (21). Next, while grabbing the end of the spool assembly (2-2) by hand and rotating, remove the spool assembly (2-2) from the base plate (2-1).
IN E
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
• Do not try to force out the spool assembly (2-2) with extreme force if the spool assembly (2-2) becomes stuck when it is being removed. If it is forced out, this could scratch the inner diameter surface of the base plate (2-1) hole or the outer diameter surface of the spool assembly (2-2). If it becomes stuck, do as follows. Lightly hit the end surface of the spool assembly (2-2) with a plastic hammer to once insert it into the base plate (2-1). After this, check that the spool assembly (2-2) moves smoothly and try again to remove it while rotating it.
TE RN
Caution: The spool assembly (2-2) and base plate (2-1) are fit together with a very small gap. For this reason, observe the following precautions when working.
• Do not perform disassembly of the spool assembly (2-2) if it is not necessary. Disassembly can cause scratching on the outer diameter surface of the spool assembly. When disassembly is necessary, contact our company. [3] Removal of relief valves (2-7) Loosen the plug (2-7-6) and remove the relief valves (2-7). Caution: The relief valves (2-7) is at a set pressure. The motor driving force and braking force are both determined by this set pressure. For this reason, do not perform the following actions. • Loosen the nut (2-7-9) and do not tamper with the locking screw (2-7-8). If this part is tampered with, the set pressure of the relief valve will change and the machine will no longer display prescribed capabilities. • Do not perform disassembly of the relief valve. The set pressure will change and the machine will no longer display prescribed capabilities.
