Practical advice Notes on maintenance work Notes on maintenance work Note: The bumper corner piece is additionally secured by a quick-release lock.
Grasp the bumper corner piece above the headlamp and pull it in the direction of the arrow against the resistance of the quick-release lock. Note: The direction of the arrow signifies: forwards and diagonally away from the centre of the vehicle.
Note:
Caution: Before the bumper corner piece is folded in, make sure that the closing tongue in the quick-release lock is correctly positioned and correct if necessary.
Danger. Risk of accident if the bumper corner piece folds out of its own accord. Both the quick-release lock and the flap lock must be heard or felt to lock into place. If necessary, check that the flap lock is correctly seated by gently pulling or jogging the bumper corner piece in the same direction as when folding it out.
Note: All scheduled maintenance tasks are described in separate instructions. The tasks listed here are not completed at set maintenance intervals, but must be performed in response to bus operation conditions.
The fold angle is limited to approximately 60° by a retention strap.
To fold the bumper corner piece in, lift it up and push it against the flap lock.
CITARO (Euro 5/EEV)/10.2011 GB
281
