Driver's area controls Turning the steering wheel when the bus is stationary Press the upper section of switch (1). The steering wheel and instrument panel are locked in their current position.
Turning the steering wheel when the bus is stationary Observe the instructions and information.
Caution: Never have more than one person turn the steering wheel. Do not pull the steering wheel on one side only.
Note: To prevent damage to the steering column, the following points must be observed when turning the steering wheel with the bus stationary, without hydraulic support (engine switched off) and without a turntable under the front wheels (tyres in direct contact with the ground):
Note: We ask the workshop in particular to note this.
Release the steering wheel adjuster and push the steering wheel fully down. Lock the steering wheel adjuster in place. Turn the steering wheel using both hands placed apart at an angle of between 90° and 180°.
CITARO (Euro 5/EEV)/10.2011 GB
171
