Driver's area controls Manual centring of the trailing axle Manual centring of the trailing axle Electrical system on Bus travelling less than 12 mph (20 km/h)
Note: Without manual centring, the steering angle of the trailing axle is continuously returned to 0° at a speed of between 12 mph (20 km/h) and 20 mph (35 km/h).
Note: If the trailing axle is centred, the rear end of the bus will swing out less and the turning circle (w to w) will increase. M54.00-1758-71
“Pull-away aid active” indication display (2) on the display screen goes out.
Note: The trailing axle is always centred automatically whenever the bus is travelling faster than 20 mph (35 km/h).
Note: The pull-away aid is deactivated automatically as soon as the bus travels faster than 20 mph (30 km/h). “Pull-away aid active” indication display (2) on the display screen goes out.
160
CITARO (Euro 5/EEV)/10.2011 GB
Note: Without manual centring, the trailing axle is steered fully in proportion to the front axle at speeds of up to 12 mph (20 km/h).
M54.00-1759-71
Press and hold the upper section of pushbutton (3) until the indicator lamp lights up. The trailing axle is centred parallel to the driven axle.
