Driver's area controls Menu structure 1 1.1 1.2 2 2.1 2.2 3 3.1 3.2 4 4.1 4.2 4.3 4.4 5 5.1 5.2 5.3 5.4
“Vehicle” main menu Doors and flaps Reversing camera / doorway II camera (option) “Assistance” main menu Operating notifications IBIS (integrated on-board information system) “Trip computer” main menu After start After reset “Monitoring” main menu Supply pressures Engine Voltage Operating notifications “Events” main menu Overview Event 1 Event 2 Event n
Menu structure Note: This overview takes all possible items of optional equipment into account. Bus-specific menu structures may differ from bus to bus.
Main menus and submenus
M54.00-1720-71
The menu system comprises five main menus arranged in a loop. The driver is able to browse from menu to menu using the main menu buttons on the steering wheel. For orientation purposes, the number (1) of the current main menu is displayed at the top left of the display window. Each main menu contains a series of submenus, which are also arranged in a loop. The number (2) identifying the submenu concerned is shown in the top right of the display. The only CITARO (Euro 5/EEV)/10.2011 GB
123
