11 Field use 11.3 Automatic mode “Unloading” – The message “Switch on PTO shaft” (symbol “PTO shaft switch on”) flashes.
27
• Switch on the PTO shaft at idle speed. • Then increase the PTO shaft speed. Observe the maximum PTO shaft speed – see Operator's Manual of the Machine Section Specifications. The unloading of the machine is thus started. (Fig. 25, 26, 27, 28)
28
11.3.2 Floor conveyor control
M
Automatic switching off / on of the floor conveyor drive via the torque threshold value of the PTO shaft is not available at the present.
M2
Torque display (M) (informative) – The black bar shows the current torque of the PTO shaft in percentage of the maximum permissible torque.
29
– In order not to overload the metering drum drive and to avoid blockages, the vertical marking (M2) should not be exceeded. – Adjust the floor conveyor speed manually to suit or – switch the floor conveyor drive off / on. (Fig. 29)
86
Erg BA QUANTUM 6800 S / P - 000 295 387 0
