11 Field use 11.2 Automatic mode “Loading”
11.2.10 Ending the automatic mode “Loading” Actuate the “Soft Key” – The loading process is ended and the machine is brought to the transport position. – Change the Soft Keys. Danger!
22
There is a danger of squashing by moving machine components. – Actuate “Soft Key” (Fig. 23) to interrupt the automatic sequence! The control system carries out the following functions automatically: – Switching off the floor conveyor drive. – Lifting the pickup completely. – Switching off the pickup drive. – Closing knife frame. – Activating drawbar damping.
23 After the transport position is reached: – The display changes to the menu “Transport”.
• Disengage the PTO shaft (Fig. 22, 23, 24)
24
84
Erg BA QUANTUM 6800 S / P - 000 295 387 0
