11 Field use 11.2 Automatic mode “Loading”
11.2.6 Opening / closing the knife frame completely Danger! The knife frame can be closed from the tractor. There is a danger of squashing by moving machine components. – Switch off engine. – Remove the ignition key. When working on / in the knife frame there is an increased risk of injury from the sharp machine components! – Wear gloves.
Opening the knife frame If the knife frame is to be opened completely (e.g. to change blades, for repair work or for removing the rotor): Actuate the “Soft Key” – in order to open the knife frame. Symbol appears in the status bar. – The Terminal emits an acoustic signal. 13
– The blades are still located in the guide of the knife frame. Danger! Pushing the button (S3) automatically lowers the pickup down to the floor. There is a danger of squashing by moving machine components. – Maintain adequate distance to the pickup.
S3
Push the button (S3) above the knife frame in order to fully open the knife frame. 68387
14 – The blades are located outside the guide of the knife frame. (Fig. 13, 14)
80
Erg BA QUANTUM 6800 S / P - 000 295 387 0
