11 Field use 11.2 Automatic mode “Loading”
• Switch on the PTO shaft at idle speed. • Then increase the PTO shaft speed. Observe the maximum PTO shaft speed – see Operator's Manual of the Machine Section Specifications. The machine is thus ready for loading. (Fig. 1, 2, 3, 4)
4
11.2.2 Headland – Lifting / lowering pickup Lifting the pickup Actuate “Soft Key” in order to lift the pickup up. Symbol appears in the data field. – The pickup drive remains switched on. Lowering the pickup Danger! 5
The hydraulic cylinder for the knife frame is briefly pressurised to compensate for leaks. There is a danger of squashing by moving machine components. – Actuate the “Soft Key” in order to end the procedure! Actuate the “Soft Key” again in order to lower the pickup into the working position (float position). Note!
6
If the front wagon is adjusted during use, the front wagon is completely lowered again loading mode. – The knife frame is pulled closed briefly. (Fig. 5, 6)
000 295 387 0 - Erg BA QUANTUM 6800 S / P
77
