10 Operation – ISOBUS Terminal 10.14 Manual mode “Unloading”
10.14.1 Calling up the menu “Manual unloading” Actuate the “Soft Key” – to call up the “Unloading” start menu. – The display changes to the start menu “Unloading”. The “Unloading” menu is active – the symbol “Unloading” is shown inverted in the menu bar (Fig. 14). (Fig. 13, 14) 13 Actuate the “Soft Key” (Fig. 14) – to call up the “Manual Unloading” menu. – The display changes to the menu “Manual Unloading” (Fig. 15). The “Manual Unloading” menu is active – the symbol “Manual Unloading” is shown inverted in the menu bar.
• If necessary, switch on the PTO shaft at idle tractor engine speed.
• Then increase the PTO shaft speed. 14
Observe the maximum PTO shaft speed – see Operator's Manual of the Machine Section Specifications. Actuate the “Soft Key” – to leave the menu “Manual Unloading” and to return to the “Auto Unloading” menu. – For further information see Automatic mode “Unloading”, page 85. Menu “Setup” – For further information see Menu “Setup”, page 50.
15
68
(Fig. 14, 15)
Erg BA QUANTUM 6800 S / P - 000 295 387 0
