10 Operation – ISOBUS Terminal 10.13 Manual mode “Loading” Actuate the “Soft Key” – in order to reverse the floor conveyor drive. Symbol appears. – The floor conveyor runs at the set reversing speed as long as the “Soft Key” is depressed (inching function). – Release “Soft Key”, floor conveyor continues to run in the normal direction. (Fig. 9, 10) 9
10
10.13.4 End of loading operation In addition to the filling level display (optional equipment), the machine is equipped with a switch which shows the full load. – The floor conveyor gradually moves the crop to the back. – In the end the crop is pressed against the metering drums. – The metering drums are thus pushed slightly backwards. 11
– The switch contact is made. – The message “Wagon full” is displayed in the data field. – The floor conveyor drive is switched off.
• Disengage the PTO shaft (Fig. 11)
66
