10 Operation – ISOBUS Terminal 10.10 Menu “Order management” If required, a designation for the order can be entered. No designation is required for the evaluation of the order data.
• Select the data field and enter the designation. ISOBUS Terminal:
• See the Operator's Manual of the terminal in question. (Fig. 58)
58 CLAAS Communicator:
• “Terminal” button, see page 25. Turn the “Terminal” button until the data field (H) appears with a border around it.
H
59
CLAAS Communicator
• Push the “Terminal” button, the displays change to the menu “Data input”. (Fig. 59)
Moving the insertion marker (M)
• Turn the “Terminal” button until the desired direction arrow (B) is highlighted. move to the right M
move to the left
• Press the “Terminal” button so many times until the insertion marker is at the desired location. 1x pressing = Move the insertion marker one character to the right or to the left.
B CLAAS Communicator
000 295 387 0 - Erg BA QUANTUM 6800 S / P
60
(Fig. 60)
