7 Mounting and removing the machine
7 Mounting and removing the machine 7.2 Removing / storing the machine
7.2
Removing / storing the machine Danger! All work under or on the machine lifted up should only be undertaken with the machine securely propped up - danger of injury. – The machine must be securely supported underneath. – Use suitable supporting elements. – see also Operator's Manual of the machine. The drive and the engine must always be switched off when working on the machine. – Switch off engine. – Remove the ignition key.
Caution! The machine must only be parked on flat ground - stability!
• Machine to be unhooked in accordance with the Operator's Manual for the machine. Machine with ISOBUS Terminal
Attention! 10
Dampness in the terminal / CLAAS Communicator leads to functional errors in the electro-hydraulic control system of the machine!
11
– Protect the Terminal / CLAAS Communicator from dampness.
• Remove the terminal / CLAAS Communicator (10) from the tractor and store away from dampness.
• Fix the CLAAS Communicator to the bracket (11) 3
underneath the front cladding.
• Also observe the instructions in the Operator's Manual for the terminal being used with regard to storage. (Fig. 3)
16
Erg BA QUANTUM 6800 S / P - 000 295 387 0
